Load center, Homeline, 1 phase, 8 spaces, 16 circuits, 200A convertible main breaker, PoN, NEMA3R, feedthru

Name: Load center, Homeline, 1 phase, 8 spaces, 16 circuits, 200A convertible main breaker, PoN, NEMA3R, feedthru
Brand: United Electric
SKU: HOM816M200PFTRB
Price: 832.11 USD
Availability: InStock

MFR #: HOM816M200PFTRB

UPC: 78590197395

Product #: 567836

Part Number:

HOM816M200PFTRB HOM OUTD 200AMB 8/16CIR FT LUGS SQUARED

$832.11 / ea $840.52 / ea

Enter Quantity

Features

SQD SCHNEIDER-ELECTRIC HOM816M200PFTRB

Specifications

Brand Square D
Bus Rated Current - Metric 225
Cable Size AWG 4...250 kcmil copper or aluminium
Cover Type Surface cover
Depth - Metric 115
Device Composition Grounding bar (ordered separately)
Electrical Connection Feed-thru lugs
Enclosure 6R;Baked enamel Gray;Welded galvannealed steel
Height - Metric 758
Line Rated Current - Metric 200
Load Center Type PoN Convertible Mains (breaker)
Manufacturer Schneider Electric
Nema Degree Of Protection NEMA 3R weatherproof enclosure
Number Of Circuits 16
Number of Spaces 8
Number Of Tandem Circuit Breakers 8
Phase 1
Provided Equipment Circuit-breaker 1 ) 2P 200 A 120/240 V AC main supply ready assembled
Rated Operational Voltage 120/240 V AC
Short Description HOM816M200PFTRB HOM OUTD 200AMB 8/16CIR FT LUGS SQUARED
Short-circuit Current - Metric 22
Special Features Tin plated aluminium: busbar
Type Load Center
Width - Metric 375
Wiring Configuration 3-Wire
