All in one, Homeline, CSED, ringed socket, 225A, semi flush mount, 30 spaces, 42 circuits, 22kA SCCR, no bypass, solar ready

Name: All in one, Homeline, CSED, ringed socket, 225A, semi flush mount, 30 spaces, 42 circuits, 22kA SCCR, no bypass, solar ready
Brand: United Electric
SKU: SC3042M225PF
Price: 2257.2 USD
Availability: InStock

MFR #: SC3042M225PF

UPC: 785901109549

Product #: 893386

Part Number:

SC3042M225PF ALL IN ONE HOMELINE CSED RINGED SOCKET 225A SEMI FLUSH MOUNT 30 SPACES 42 CIRCUITS 22KA SCCR NO BYPASS SOLAR READY SQUARE D

$2,257.20 / ea $2,280.00 / ea

Enter Quantity

Features

Square D SC3042M225PF ALL IN ONE HOMELINE CSED RINGED SOCKET 225A SEMI FLUSH MOUNT 30 SPACES 42 CIRCUITS 22KA SCCR NO BYPASS SOLAR READY

Specifications

Awg Gauge AWG 12...AWG 2/0 (aluminium) service ground;AWG 4...250 kcmil (aluminium/copper) line side;AWG 14...AWG 2/0 (copper) service ground
Brand Square D
Bus Rated Current - Metric 225
Bypass Type No bypass
Connections - Terminals Plug-on neutral
Device Composition Service disconnect (factory installed)
Device Mounting Semi flush
Electrical Connection Lugs, line side;lugs, service ground
Line Rated Current - Metric 225
Manufacturer Schneider Electric
Number Of Circuits 42
Number of Spaces 30
Number Of Tandem Circuit Breakers 12
Phase 1 phase
Product Compatibility Solar ready
Product Or Component Type All-In-One
Range Of Product Homeline
Service Feed Location OH with field installed tunnel kit;UG
Short Description SC3042M225PF ALL IN ONE HOMELINE CSED RINGED SOCKET 225A SEMI FLUSH MOUNT 30 SPACES 42 CIRCUITS 22KA SCCR NO BYPASS SOLAR READY SQUARE D
Short-circuit Current - Metric 22
Tightening Torque Main lugs 250 lb.in, AWG 4...250 kcmil, aluminium/copper;service ground 50 lb.in, AWG 14...AWG 2/0, copper;service ground 50 lb.in, AWG 12...AWG 2/0, aluminium;branch lugs 50 lb.in, AWG 14...AWG 4, copper;branch lugs 50 lb.in, AWG 12...AWG 2, aluminium;branch lugs 35 lb.in, AWG 6...AWG 4, aluminium/copper;branch lugs 25 lb.in, AWG 8, aluminium/copper;branch lugs 20 lb.in, AWG 14...AWG 10, aluminium/copper;branch lugs 20 lb.in, AWG 12...AWG 10, aluminium/copper;Cover 10 lb.in
