Meter mains, Homeline, CSED, ringless socket, 200A, surface mount, maximum 8 spaces, 16 circuits, no bypass

Name: Meter mains, Homeline, CSED, ringless socket, 200A, surface mount, maximum 8 spaces, 16 circuits, no bypass
Brand: United Electric
SKU: RC816F200C
Price: 1214.73 USD
Availability: InStock

MFR #: RC816F200C

UPC: 785901863922

Product #: 57848

Part Number:

RC816F200C 86392 METER MAIN RINGLESS OH/UG 200A SQUARE D

$1,214.73 / ea $1,227.00 / ea

Enter Quantity

Features

SQUARE D RC816F200C METER MAINS RINGLESS 200A 22KA BRANCH SP: 8 OH/UG QOM2200VH (FACTORY INSTALLED) 200A FEED-THRU LUGS SURFACE MOUNT 200A 16 8 A 1 #6 TO 350 AWG/KCMIL (AL/CU) #12 TO #2/0 AWG (AL/CU)

Specifications

Brand Square D
Bus Rated Current - Metric 200
Device Composition Service disconnect (factory installed)
Electrical Connection Lugs, line side;feed-thru lugs, service ground
Line Rated Current - Metric 200
Manufacturer Schneider Electric
Number Of Circuits 16
Number of Spaces 8
Number Of Tandem Circuit Breakers 8
Service Feed Location OH;UG
Short Description RC816F200C 86392 METER MAIN RINGLESS OH/UG 200A SQUARE D
Short-circuit Current - Metric 22
Tightening Torque Main lugs 250 lb.in, AWG 6...350 kcmil, aluminium/copper;service ground 50 lb.in, AWG 14...AWG 2/0, copper;service ground 50 lb.in, AWG 12...AWG 2/0, aluminium;branch lugs 35 lb.in, AWG 6...AWG 4, aluminium/copper;branch lugs 25 lb.in, AWG 8, aluminium/copper;branch lugs 20 lb.in, AWG 14...AWG 10, copper;branch lugs 20 lb.in, AWG 12...AWG 10, aluminium;Cover 10 lb.in
