Meter mains, Homeline, CSED, ringless socket, 150A, surface mount, maximum 8 spaces, 16 circuits, no bypass

Name: Meter mains, Homeline, CSED, ringless socket, 150A, surface mount, maximum 8 spaces, 16 circuits, no bypass
Brand: United Electric
SKU: RC816F150C
Price: 1175.13 USD
Availability: InStock

MFR #: RC816F150C

UPC: 785901859192

Product #: 722940

Part Number:

RC816F150C METER MAIN RINGLESS OH/UG 150A SQUARE D

$1,175.13 / ea $1,187.00 / ea

Enter Quantity

Features

SQUARE D RC816F150C SQUARE D METER MAIN RINGLESS OH/UG 150A 1 PHASE 120/240 V AC 150 A 150 A 150 A HOMELINE METER MAINS NEMA 3R OH/UG SERVICE EQUIPMENT UL LISTED NO BYPASS RINGLESS SURFACE

Specifications

Awg Gauge AWG 6...350 kcmil aluminium/copper)line side;AWG 12...AWG 2/0 aluminium/copper)service ground
Brand Square D
Bus Rated Current - Metric 200
Bypass Type No bypass
Device Composition Service disconnect (factory installed)
Device Mounting Surface
Electrical Connection Lugs, line side;feed-thru lugs, service ground
Line Rated Current - Metric 150
Manufacturer Schneider Electric
Number Of Circuits 16
Number of Spaces 8
Number Of Tandem Circuit Breakers 8
Product Or Component Type Meter Mains
Range Of Product Homeline
Service Feed Location OH;UG
Short Description RC816F150C METER MAIN RINGLESS OH/UG 150A SQUARE D
Short-circuit Current - Metric 22
Tightening Torque Main lugs 250 lb.in, AWG 6...350 kcmil, aluminium/copper;service ground 50 lb.in, AWG 14...AWG 2/0, copper;service ground 50 lb.in, AWG 12...AWG 2/0, aluminium;branch lugs 35 lb.in, AWG 6...AWG 4, aluminium/copper;branch lugs 25 lb.in, AWG 8, aluminium/copper;branch lugs 20 lb.in, AWG 14...AWG 10, copper;branch lugs 20 lb.in, AWG 12...AWG 10, aluminium;Cover 10 lb.in
