Generator panel, QO, 1 phase, 4 spaces, 8 circuits, 60A main breaker with interlock, NEMA1, surface cover door, UL

Name: Generator panel, QO, 1 phase, 4 spaces, 8 circuits, 60A main breaker with interlock, NEMA1, surface cover door, UL
Brand: United Electric
SKU: QO48M60DSGP
Price: 557.37 USD
Availability: InStock

MFR #: QO48M60DSGP

UPC: 785901824343

Product #: 127941

Part Number:

QO48M60DSGP 82434 LOADCTR QO MB GEN PANEL 240V 60A 1PH 4SP SQUARE D

$557.37 / ea $563.00 / ea

Enter Quantity

Features

SQUARE D QO48M60DSGP LOAD CENTER CONVERTIBLE MAINS - BREAKER 60A 1-PHASE NEMA 1 4 SPACE(S) 10KA 4 INDOOR SURFACE (WITH DOOR) ORDER SEPARATELY 120/240 VAC

Specifications

Brand Square D
Cable Size AWG 8...AWG 2 aluminium/copper
Cover Type Surface cover with door
Depth - Metric 97
Device Composition Grounding bar (ordered separately)
Electrical Connection Lugs
Enclosure 4;Baked enamel Gray;Welded sheet steel
Height - Metric 319
Line Rated Current - Metric 60
Load Center Type Main breaker
Manufacturer Schneider Electric
Number Of Circuits 8
Number of Spaces 4
Number Of Tandem Circuit Breakers 4
Phase 1
Short Description QO48M60DSGP 82434 LOADCTR QO MB GEN PANEL 240V 60A 1PH 4SP SQUARE D
Short-circuit Current - Metric 10
Special Features Tin plated aluminium: busbar
Tightening Torque Cover 20 lb.in
Type Panel
Width - Metric 226
Wiring Configuration 3-Wire
