Load center, QO, 1 phase, 8 spaces, 16 circuits, 200A convertible main breaker, NEMA3R, feedthru lugs, UL

Name: Load center, QO, 1 phase, 8 spaces, 16 circuits, 200A convertible main breaker, NEMA3R, feedthru lugs, UL
Brand: United Electric
SKU: QO1816M200FTRB
Price: 854.37 USD
Availability: InStock

MFR #: QO1816M200FTRB

UPC: 785901868187

Product #: 121681

Part Number:

QO1816M200FTRB 86818 LD CTR QO MB 240V 200A 1PH 8SP NEMA3R FT SQUARE D

$854.37 / ea $863.00 / ea

Enter Quantity

Features

SQUARE D QO1816M200FTRB LOAD CENTER CONVERTIBLE MAINS - BREAKER 200A 1-PHASE NEMA 3R 8 SPACE(S) 22KA 8 OUTDOOR/RAINPROOF SURFACE ORDER SEPARATELY 120/240 VAC

Specifications

Brand Square D
Cable Size AWG 4...250 kcmil aluminium/copper
Cover Type Surface cover
Device Composition Grounding bar (ordered separately)
Electrical Connection Feed-thru lugs
Enclosure 6R;Baked enamel Gray;Welded galvannealed steel
Enclosure Type Weatherproof enclosure
Height - Metric 758
Line Rated Current - Metric 200
Load Center Type Main breaker
Manufacturer Schneider Electric
Number Of Circuits 16
Number of Spaces 8
Number Of Tandem Circuit Breakers 8
Phase 1
Rated Operational Voltage 120/240 V AC
Short Description QO1816M200FTRB 86818 LD CTR QO MB 240V 200A 1PH 8SP NEMA3R FT SQUARE D
Short-circuit Current - Metric 22
Special Features Tin plated copper: busbar
Type Load Center
Width - Metric 375
Wiring Configuration 3-Wire
