Load center, QO, 1 phase, 42 spaces, 52 circuits, 200A convertible main breaker, PoN, NEMA1, Qwik-grip, UL

Name: Load center, QO, 1 phase, 42 spaces, 52 circuits, 200A convertible main breaker, PoN, NEMA1, Qwik-grip, UL
Brand: United Electric
SKU: QO142M200PQ
Price: 1236.51 USD
Availability: InStock

MFR #: QO142M200PQ

UPC: 785901609667

Product #: 695369

Part Number:

QO142M200PQ QO QWIK GRIP PLUG ON NEUTRAL LC N1 1PH MB 200A 42 SPACES SQUARED

$1,236.51 / ea $1,249.00 / ea

Enter Quantity

Specifications
Resources

Specifications

Awg Gauge AWG 4...300 kcmil aluminium/copper
Box Number 11Q
Brand Square D
Depth - Metric 95
Device Composition Grounding bar (ordered separately)
Enclosure Material Welded sheet steel
Height - Metric 1000
Line Rated Current - Metric 200
Load Center Type PoN Convertible Mains (breaker)
Manufacturer Schneider Electric
Material Copper: busbar
Number Of Circuits 52
Number of Spaces 42
Number Of Tandem Circuit Breakers 10
Phase 1 phase
Product Or Component Type Load Center
Provided Equipment Qwik grip assembly kit 1 )
Range Of Product QO
Rated Operational Voltage 120/240 V AC
Short Description QO142M200PQ QO QWIK GRIP PLUG ON NEUTRAL LC N1 1PH MB 200A 42 SPACES SQUARED
Short-circuit Current - Metric 22
Tightening Torque Cover 20 lb.in
Width - Metric 362
