Load center, QO, 1 phase, 30 spaces, 30 circuits, 200A convertible main breaker, PoN, NEMA1, UL

Name: Load center, QO, 1 phase, 30 spaces, 30 circuits, 200A convertible main breaker, PoN, NEMA1, UL
Brand: United Electric
SKU: QO130M200P
Price: 1032.57 USD
Availability: InStock

MFR #: QO130M200P

UPC: 785901242536

Product #: 508649

Part Number:

QO130M200P QO PLUG-ON NEUT LC N1 1PH MB 240V 200A SQUARE D

$1,032.57 / ea $1,043.00 / ea

Enter Quantity

Features

SQD SCHNEIDER-ELECTRIC QO130M200P QO PLUG-ON NEUT LC N1 1PH MB 240V 200A

Specifications

Awg Gauge AWG 4...250 kcmil aluminium/copper
Box Number 9
Brand Square D
Cover Type Order separately
Device Composition Grounding bar (ordered separately)
Electrical Connection Lugs
Enclosure Material Welded sheet steel
Height - Metric 758
Line Rated Current - Metric 200
Load Center Type PoN Convertible Mains (breaker)
Manufacturer Schneider Electric
Material Tin plated copper: busbar
Number Of Circuits 40
Number of Spaces 30
Number Of Tandem Circuit Breakers 10
Phase 1 phase 3 wires
Product Or Component Type Load Center
Range Of Product QO
Rated Operational Voltage 120/240 V AC
Short Description QO130M200P QO PLUG-ON NEUT LC N1 1PH MB 240V 200A SQUARE D
Short-circuit Current - Metric 22
Tightening Torque Cover 20 lb.in
Width - Metric 362

Resources

Product Brochure

Spec Sheet

Technical Drawing
