Load center, QO, 1 phase, 30 spaces, 34 circuits, 125A convertible main lugs, PoN, NEMA1, gnd bar, UL

Name: Load center, QO, 1 phase, 30 spaces, 34 circuits, 125A convertible main lugs, PoN, NEMA1, gnd bar, UL
Brand: United Electric
SKU: QO130L125PG
Price: 579.15 USD
Availability: InStock

MFR #: QO130L125PG

UPC: 785901121411

Product #: 731422

Part Number:

QO130L125PG PLUG-ON NEUTRAL LOAD CENTER 125A MLO 30CIR

$579.15 / ea $585.00 / ea

Enter Quantity

Specifications
Resources

Specifications

Awg Gauge AWG 6...AWG 2/0 aluminium/copper
Box Number 7
Brand Square D
Cover Type Order separately
Depth - Metric 95
Device Composition Grounding bar included (not installed)
Electrical Connection Lugs
Enclosure Material Welded sheet steel
Height - Metric 758
Line Rated Current - Metric 125
Load Center Type PoN Convertible Mains (lugs)
Manufacturer Schneider Electric
Material Tin plated copper: busbar
Number Of Circuits 34
Number of Spaces 30
Number Of Tandem Circuit Breakers 4
Phase 1 phase 3 wires
Product Or Component Type Load Center
Range Of Product QO
Rated Operational Voltage 120/240 V AC
Short Description QO130L125PG PLUG-ON NEUTRAL LOAD CENTER 125A MLO 30CIR
Short-circuit Current - Metric 65
Tightening Torque Main lugs 50 lb.in, AWG 6...AWG 2/0, aluminium/copper;Cover 20 lb.in
Width - Metric 362
