Panelboard interior, NQ, main lugs, 400A, Al bus, 42 pole spaces, 3 phase, 4 wire, 240VAC, 48VDC

Name: Panelboard interior, NQ, main lugs, 400A, Al bus, 42 pole spaces, 3 phase, 4 wire, 240VAC, 48VDC
Brand: United Electric
SKU: NQ442L4
Price: 1991.88 USD
Availability: InStock

MFR #: NQ442L4

UPC: 785901507895

Product #: 216401

Part Number:

NQ442L4 50789 PNLBD INT NQ 400A MLO 42 CKT 3P AL SQUARE D

$1,991.88 / ea $2,012.00 / ea

Enter Quantity

Features

SQD SCHNEIDER-ELECTRIC NQ442L4 PNLBD INT NQ 400A MLO 42 CKT 3P AL

Specifications

Brand Square D
Circuit Breaker Type QOB;QOB-VH;QHB
Connections - Terminals Lug line AWG 1/0...750 kcmil aluminium;lug neutral AWG 1/0...750 kcmil aluminium
Enclosure Nominal Depth 5.75 in NEMA 1;6.5 in NEMA 3R/5/12
Enclosure Nominal Height 50
Enclosure Nominal Width 20
Line Rated Current - Metric 400
Load Center Type Main lugs
Manufacturer Schneider Electric
Material Aluminium
Number of Spaces 42
Phase 3 phase
Rated Interrupted Current - Metric 10
Rated Operational Voltage 240 V AC;48 V DC
Short Description NQ442L4 50789 PNLBD INT NQ 400A MLO 42 CKT 3P AL SQUARE D
Tightening Torque 31.07-33.90 N.m 53.48-380 mm² (AWG 1/0...750 kcmil);31.07-33.90 N.m 53.48-177.3 mm² (AWG 1/0...350 kcmil);62.14-62.14 N.m 53.48-380 mm² (AWG 1/0...750 kcmil);62.14-62.14 N.m 53.48-152 mm² (AWG 1/0...300 kcmil);42.37-42.37 N.m 53.48-380 mm² (AWG 1/0...750 kcmil);42.37-42.37 N.m 53.48-152 mm² (AWG 1/0...300 kcmil)
Type 4-wire
