Circuit breaker, PowerPacT J, 200A, 3 pole, 600VAC, 14kA, I-Line, thermal magnetic, 80%, ABC

Name: Circuit breaker, PowerPacT J, 200A, 3 pole, 600VAC, 14kA, I-Line, thermal magnetic, 80%, ABC
Brand: United Electric
SKU: JDA36200
Price: 2838.33 USD
Availability: InStock

MFR #: JDA36200

UPC: 785901539766

Product #: 46462

Part Number:

JDA36200 53976 MOLDED CASE CIRCUIT BREAKER 600V 200A SQUARE D

$2,838.33 / ea $2,867.00 / ea

Enter Quantity

Features

SQUARE D JDA36200 MOLDED CASE CIRCUIT BREAKER (J-FRAME) 200A 3-POLE 600 VAC LOW: 1000A - HIGH: 2000A ABC 25KA@240VAC - 18KA@480VAC - 14KA@600VAC I-LINE PLUG-ON I-LINE PANELBOARDS AND SWITCHBOARDS (POWERPACT)

Specifications

Awg Gauge AWG 3/0...350 kcmil aluminium/copper terminals
Brand Square D
Breaking Capacity 25 kA 240 V AC 50/60 Hz UL 489; 18 kA 480 V AC 50/60 Hz; 14 kA 600 V AC 50/60 Hz; 20 kA 250 V DC
Breaking Capacity Code D
Circuit Breaker Application HACR rated
Communication Interface Modbus;Ethernet
Continuous Current Rating 80
Control Type Toggle
Depth - Metric 86
Device Application Distribution
Electrical Connection I-Line connection, line;lugs, load
Line Rated Current - Metric 200
Local Signalling Switched off (OFF) 1 trip indicator green)
Long Time Pick-up Adjustment Range 0.25...1 x In
Magnetic Hold Current - Metric 1000
Magnetic Tripping Current - Metric 2000
Manufacturer Schneider Electric
Mounting Height 4.5
Mounting Mode I-Line bracket)
Mounting Support Bracket
Net Weight - Metric 2.4
Network Frequency 50/60 Hz
Number Of Slots 2 auxiliary switch OF plug-in);1 alarm switch SD plug-in);1 overcurrent trip switch SDE plug-in);1 voltage release MN or MX plug-in)
Short Description JDA36200 53976 MOLDED CASE CIRCUIT BREAKER 600V 200A SQUARE D
