Load center, Homeline, 1 phase, 12 spaces, 24 circuits, 125A convertible main lugs, PoN, NEMA1, gnd bar, value pack

Name: Load center, Homeline, 1 phase, 12 spaces, 24 circuits, 125A convertible main lugs, PoN, NEMA1, gnd bar, value pack
Brand: United Electric
SKU: HOM1224L125PGCVP
Price: 305.91 USD
Availability: InStock

MFR #: HOM1224L125PGCVP

UPC: 785901864288

Product #: 567463

Part Number:

HOM1224L125PGCVP HOM VALPK INDR SQUARE D

$305.91 / ea $309.00 / ea

Enter Quantity

Features

SQD SCHNEIDER-ELECTRIC HOM1224L125PGCVP

Specifications

Brand Square D
Bus Rated Current - Metric 125
Cable Size AWG 6...AWG 1 copper;AWG 6...AWG 2/0 aluminium
Cover Type Combination flush/surface cover
Depth - Metric 95
Device Composition Grounding bar included (not installed)
Electrical Connection Lugs
Enclosure 6;Baked enamel Gray;Welded galvannealed steel
Height - Metric 455
Line Rated Current - Metric 125
Load Center Type PoN Convertible Mains (lugs)
Manufacturer Schneider Electric
Nema Degree Of Protection NEMA 1 indoor enclosure
Number Of Circuits 24
Number of Spaces 12
Number Of Tandem Circuit Breakers 6
Phase 1
Provided Equipment circuit-breaker 2 ) 1P 20A 120/240 V AC;Grounding bar 1 )
Rated Operational Voltage 120/240 V AC
Short Description HOM1224L125PGCVP HOM VALPK INDR SQUARE D
Short-circuit Current - Metric 10
Special Features Tin plated aluminium: busbar
Type Load Center
Width - Metric 362
Wiring Configuration 3-Wire

Resources

Product Brochure

Spec Sheet

Technical Drawing
