Safety switch, heavy duty, fusible, 400A, 4 wire, 3 pole, 1 neutral, 125hp, 240VAC/250VDC, NEMA 3R

Safety switch, heavy duty, fusible, 400A, 4 wire, 3 pole, 1 neutral, 125hp, 240VAC/250VDC, NEMA 3R

MFR #: H325NR

UPC: 785901451440

Product #: 44187

Part Number:

H325NR 45144 SWITCH FUSIBLE HD 240V 400A 3P NEMA 3R SQUARE D

Shipping Restrictions Apply

$4,278.78 / ea $4,322.00 / ea

Enter Quantity

Features

SQUARE D H325NR SAFETY SWITCH HEAVY DUTY 400A FUSIBLE 240 VAC/250 VDC NEMA 3R 3-POLE SINGLE THROW UL LISTED RAINPROOF AND SLEET/ICE PROOF (INDOOR/OUTDOOR) GALVANNEALED STEEL FACTORY INSTALLED NEUTRAL SURFACE

Specifications

Awg Gauge AWG 1/0...750 kcmil copper or aluminium
Brand Square D
Device Application Heavy application
Device Composition Neutral (factory installed)
Device Mounting Surface
Disconnector Device Type Fusible disconnect
Electrical Connection Lugs
Fuse Type H or K;R or J
Line Rated Current - Metric 400
Manufacturer Schneider Electric
Nema Degree Of Protection NEMA 3R galvannealed steel
Net Weight - Metric 87.1
Number of Poles 3.0
Phase 3 phase
Product Or Component Type Single Throw Safety Switch
Rated Operational Voltage 250 V DC;240 V AC
Series Name Heavy duty
Short Description H325NR 45144 SWITCH FUSIBLE HD 240V 400A 3P NEMA 3R SQUARE D
Short-circuit Current 10 kA for H or K;200 kA for R or J
Tightening Torque 550-550 lbf.in (AWG 1/0...750 kcmil)
Wiring Configuration 4-wire (3PH + G)

Resources

Product Brochure

Spec Sheet

Technical Drawing
