Safety switch, double throw, non fusible, 200A, 240VAC, 250VDC, 2 pole, 15HP, neutral, NEMA 3R, bolt on

Name: Safety switch, double throw, non fusible, 200A, 240VAC, 250VDC, 2 pole, 15HP, neutral, NEMA 3R, bolt on
Brand: United Electric
SKU: DTU224NRB
Price: 2155.23 USD
Availability: InStock

MFR #: DTU224NRB

UPC: 785901174523

Product #: 6931

Part Number:

DTU224NRB 17452 SW NOT FUSIBLE DT 200A 2P NEMA3R/NEUTRAL SQUARE D

Shipping Restrictions Apply

$2,155.23 / ea $2,177.00 / ea

Enter Quantity

Features

SQUARE D DTU224NRB SAFETY SWITCH DOUBLE THROW 200A NON-FUSIBLE 240 VAC NEMA 3R 2-POLE RAINPROOF AND SLEET/ICE PROOF (INDOOR/OUTDOOR) UL LISTED GALVANNEALED STEEL FACTORY INSTALLED NEUTRAL SURFACE 10KA

Specifications

Brand Square D
Device Composition Neutral (factory installed)
Fuse Type H or K
Line Rated Current - Metric 200
Manufacturer Schneider Electric
Mounting Surface
Nema Degree Of Protection NEMA 3
Net Weight - Metric 29.93
Number of Poles 2.0
Rated Operational Voltage 240 V AC
Series Name General duty
Short Description DTU224NRB 17452 SW NOT FUSIBLE DT 200A 2P NEMA3R/NEUTRAL SQUARE D
Short-circuit Current 10 kA H or K
Tightening Torque 340-340 lbf.in (AWG 6...300 kcmil)
Type Non-fusible disconnect switch;Double Throw Safety Switch
Wire Type AWG 6...300 kcmil copper or aluminium
