Switch, reversing drum, 5HP at 575VAC single phase, 7.5HP at 575VAC polyphase, handle operated, NEMA 4 enclosure

Name: Switch, reversing drum, 5HP at 575VAC single phase, 7.5HP at 575VAC polyphase, handle operated, NEMA 4 enclosure
Brand: United Electric
SKU: 2601BW1
Price: 768.77 USD
Availability: InStock

MFR #: 2601BW1

UPC: 785901784449

Product #: 58629

Part Number:

2601BW1 78444 DRUM SWITCH 600VAC 7.5HP B +OPTIONS SQUARE D

$768.77 / ea $776.54 / ea

Enter Quantity

Features

SQUARE D AND TELEMECANIQUE 2601BW1 DRUM SWITCH REVERSING 3-POLE 600 VAC/250 VDC STANDARD ONE-PIECE OPER. NEMA 4 1.5HP@115VAC - 3HP@230VAC - 5HP@460/575VAC 5HP@200/230VAC - 7.5HP@460/575VAC UL LISTED - CSA CERTIFIED FLUSH B

Specifications

Brand Square D
Manufacturer Schneider Electric
Maximum Horse Power Rating 1.5-1.5 hp 115 V AC, 1 phase;2-2 hp 230 V DC;3-3 hp 230 V AC, 1 phase;5-5 hp 460 V AC, 1 phase;5-5 hp 575 V AC, 1 phase;5-5 hp 200 V AC, 3 phase;5-5 hp 230 V AC, 3 phase;7.5-7.5 hp 460 V AC, 3 phase;7.5-7.5 hp 575 V AC, 3 phase;2-2 hp 115 V DC
Nema Degree Of Protection NEMA 4
Rated Operational Voltage 600 V AC;250 V DC
Short Description 2601BW1 78444 DRUM SWITCH 600VAC 7.5HP B +OPTIONS SQUARE D

Resources

Product Brochure

Spec Sheet

Technical Drawing
