Locking Devices, Twist-Lock®, Industrial, Female Insulgrip® Connector Body, 20A 3-Phase 250V AC, 3-Pole 4-Wire Grounding, NEMA L15-20R, Screw Terminal, Black and White Nylon.

Name: Locking Devices, Twist-Lock®, Industrial, Female Insulgrip® Connector Body, 20A 3-Phase 250V AC, 3-Pole 4-Wire Grounding, NEMA L15-20R, Screw Terminal, Black and White Nylon.
Brand: United Electric
SKU: HBL2423
Price: 73.51 USD
Availability: InStock

MFR #: HBL2423

UPC: 783585038216

Product #: 21083

Part Number:

HUBHBL2423 LKG CONN 20A 3P 250V L15-20R B/W HBL2423 HUBBELL

$73.51 / ea

Enter Quantity

Features

HUBBELL HBL2423 LOCKING DEVICES TWISTLOCK INDUSTRIAL FEMALE CONNECTOR BODY 23-PHASEDELTA 250V AC 3-POLE 4-WIRE GROUNDING L15-20R SCREW TERMINAL BLACKAND WHITE

Specifications

Amperage Rating 20
Application Heavy Duty Industrial
Brand WIRING DEVICE-KELLEMS
Color Black;White
Conductor Range, Maximum 10
Conductor Range, Minimum 12
Connection Pressure Screw Terminal
Cord Diameter 0.350-1.150
Current Rating 20
Environmental Conditions Indoor Dry Unless Protected By Additional Means
FEATURES - Bullets Clear, funnel shaped wire entry for ease of termination.;Integral dust shield protects wiring chamber from dust or contaminants.;Superior cord grip design protects terminations from excess strain.
Insulation Insulated Body
Manufacturer Hubbell Wiring Device-Kellems
Material Nylon
Mounting Cord
NEMA Rating L15-20R
Number of Conductors 4
Number of Poles 3-Pole
Pallet Quantity 3060
Performance Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 2,000V minimum;Environmental - Flammability - HB or better per UL94 or CSA 22.2 No. 0.6;Environmental - Moisture Resistance - IP20 Suitability;Environmental - Operating Temperatures - Maximum Continuous 75°C Minimum -40°C (w/o impact);Mechanical - Terminal Accommodation - #16 AWG - #8 AWG stranded copper wire only.;Mechanical - Terminal Identification - Terminals identified in accordance with UL 498
Short Description HUBHBL2423 LKG CONN 20A 3P 250V L15-20R B/W HBL2423 HUBBELL
Special Features Standard Product
Temperature Rating, Maximum 167
Temperature Rating, Minimum -13
Type Connector Body
Voltage Rating 3 Phase 250
