Straight Blade Devices, Receptacles, Duplex, Load Controlled, 20A 125V, 2-Pole 3-Wire Grounding, 5-20R, Back and Side Wired, White

Name: Straight Blade Devices, Receptacles, Duplex, Load Controlled, 20A 125V, 2-Pole 3-Wire Grounding, 5-20R, Back and Side Wired, White
Brand: United Electric
SKU: BR20C2WHI
Price: 14.79 USD
Availability: InStock

MFR #: BR20C2WHI

UPC: 78358555141

Product #: 639158

Part Number:

HUBBR20C2WHI 2/2 CONTROLLED 20A 125V B/S DUP WH BR20C2WHI HUBBELL

$14.79 / ea

Enter Quantity

Note: this product is only sold in multiples of 1

Features

HUBBELL BR20C2WHI HUBBELL WIRING DEVICE KELLEMS STRAIGHT BLADE DEVICES RECEPTACLES DUPLEX LOAD CONTROLED 20A 125V 2-POLE 3-WIRE GROUNDING 5-20R BACKAND SIDE WIRED WHITE

Specifications

Amperage Rating 20
Application Commercial Specification Grade Duplex
Brand WIRING DEVICE-KELLEMS
Connection Terminal Screws
Description - Long Straight Blade Devices, Receptacles, Duplex, Load Controlled, 20A 125V, 2-Pole 3-Wire Grounding, 5-20R, Back and Side Wired, White
Dielectric Strength Withstands 2,000V minimum
Environmental Conditions Indoor Dry Unless Protected By Additional Means
EU RoHS Indicator Contact Manufacturer
Family Color White
Manufacturer Hubbell Wiring Device-Kellems
Material Nylon
Mounting Screw Mount
NEMA Rating 5-20R
Number of Poles 2-Pole
Number of Wires 3-Wire
Performance Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 2,000V minimum;Environmental - Flammability - UL 94 V-2;Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact);Mechanical - Product Identification - Ratings are a permanent part of the device;Mechanical - Terminal Accommodation - #14-#10 AWG stranded or solid copper wire only;Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
Phase 1
Series Controlled
Short Description HUBBR20C2WHI 2/2 CONTROLLED 20A 125V B/S DUP WH BR20C2WHI HUBBELL
Size 1.32 in x 0.83 in x 3.28 in
Special Features Controlled
Type Two Controlled Faces
Voltage Rating 125 V
Voltage Rating Description 125 V
Wattage 2500;2500.0000
Wire Size #14 to #10
